3S 300MiNi OTDR is a useful and perfect mutli-function testing meter. It is good at identifying fiber optic breakpoints, measuring fiber optic cable length and caculating fiber optic link loss. It's the cost effective fiber optical testing instrument for contractors. It combines 8 functions as below.
Fiber Optic Testing Functions:
OTDR
Optical Light Source(OLS)
Optical Power Meter(OPM)
Visual Fault Locator(VFL)
RJ45 Cable Testing Functions:
RJ45 Cable Sequence
RJ45 Cable Tracker(optional)
Other Functions:
Loss Testing
Event Map
Flash Light
Application:
FTTx Network Testing
CATV Network Testing
Access Network Testing
LAN Network Testing
3S 300MiNi OTDR is a useful and perfect mutli-function testing meter. It is good at identifying fiber optic breakpoints, measuring fiber optic cable length and caculating fiber optic link loss. It's the cost effective fiber optical testing instrument for contractors. It combines 8 functions as below.
Fiber Optic Testing Functions:
OTDR
Optical Light Source(OLS)
Optical Power Meter(OPM)
Visual Fault Locator(VFL)
RJ45 Cable Testing Functions:
RJ45 Cable Sequence
RJ45 Cable Tracker(optional)
Other Functions:
Loss Testing
Event Map
Flash Light
Application:
FTTx Network Testing
CATV Network Testing
Access Network Testing
LAN Network Testing
General Specification
Display
Colorful Screen, 3.5 inch
Interface
1xUSB, 1xOTDR, 1xVFL, 1xOPM, 1xCharging Port 1xRJ45 Port, 1x Memory Card Port
Power Supply
100V(ac) to 240V(ac), 50~60Hz
Battery
4000mAH Lithium battery
Operating Time: 12hours, Telcordia GR-196-CORE
Power Saving
Back light: 0% to 100%, Auto off: 10 to 60mins
Data Storage
Internal memory: 500 curves, TF card supported
Language
English in Default
Environmental Conditions
Operating temperature and humidity: -10℃~+50℃, ≤95% (non-condensation)
Storage temperature and humidity: -20℃~+75℃, ≤95% (non-condensation)
